Topsort plastic belt color sorter is designed for sorting the multi-color mixed plastic (PET/HDPE/ABS/PP/PS) flakes and helping you obtain higher purity raw materials and better profits.
Payment :
TT/LCProduct Origin :
Hefei,ChinaColor :
White,can customizeShipping Port :
Shanghai/NingboLead Time :
Within 15 working daysCertificate :
CEProduct Name :
Plastic Belt Color SorterWarranty :
2 yearsModel :
BSC-1200Machine Function :
Color/size/shape/material sortingTOPSORT plastic colour sort machine integrates advanced visible light sorting technologies.
Through the analysis of the visible light color and shape of the material, it can efficiently identify all kinds of plastics of different colors and ensure that the plastics are efficiently recycled and reused.
The design of every detail of the product fully considers the user's usage habits, makes operation and maintenance simple and convenient, and strives to bring you the ultimate user experience.
Belt Color Sorter Working Principle
1.Feeding: The plastic materials are fed into the color sorter machine through a hopper.
2.Scanning: The plastic materials are then scanned by a high-resolution camera system that captures images of each individual piece of plastic.
3.Color Recognition: The camera system identifies the color of each piece of plastic by analyzing the color spectrum of the reflected light.
4.Separation: Based on the color identification, the color sorter machine separates the plastic materials into different streams, using air jets.
5.Collection: The sorted plastic materials are then collected in individual containers or bags, ready for further processing or shipment.
6.Overall, the working principle of a plastic color sorter is based on the sophisticated technology of color recognition and separation, which enables efficient and accurate sorting of different types of plastic based on their color.
Technical Parameters
Model | BSC-1200 |
Channles | 256 |
Power | 3.5kw |
Weight | 1200kgs |
Dimensions | 3240*1860*1630mm |
Power voltage | 220V/50HZ/60HZ |
Sorting accuracy | 99.99% |
Capacity | 800-1200kgs/h |
Air consumption | <3.5m3/min |
Air pressure | 0.6-0.8Mpa |
Superb Plastic Sorting Sulotions
Topsort Color Sorter Machine Core Advantages
1. Latest UHD imaging and analysis technology,high-speed processing,accurate identification.
2. High level AI self-learning function,one-key automation,user friendly interface,easy operation.
3. Multi-function,multi-purpose,widely used for all kinds of plastic flakes,such as PET,PP,ABS.HDPE,LDPE.
4. Most unique intelligent LED with cold shadowless light source and super long life span, high lighting efficiency
5. Excellent combination of mechanical structure and tri-chromatic control system, guarantee 99.99% accuracy and amazing 40:1 rejection rate.
6. Ampere Altra processor from USA,Samsung from Korea,Toshiba Camera Core From Japan,Top Specification.
7. Remote control, multi-screen interaction and non-contact control for global.
8. High quality ejector with 5-10 billion ejections life low air consumption.
Sucessful Cases
Why Choose TOPSORT Color Sorter?
1. Over 18 years experience which focus on sorter machine. One of the most advanced manufacturer in Hefei, Anhui.
2. After-Sales service guarantee: We have a professional after sales service team, one-to-one customer service to help customers install and debug.
3. We have service station over Southeast Asia, co-operate re-seller in more than 100 countries.
4. Quality assurance of raw materials: the raw material we purchase are certified qualified products.
5. Quality process assurance: We have been authorized by CE & ISO quality management system, each process of production are under strictly standard.
6. System test: Our technical engineers check the product performance, even every part is subjected to rigorous aging test to ensure that the factory products would being in full compliance with customer requirements.
7. Shipping guarantee: We have professional packaging operation team, independent export qualification to ensure product safety and stability to reach customers in the hands.
Package And Delivery
Our products use professional wooden cases with PE plastic bag.
Package size will depend on each model size.
Delivery Details:
Within 10-15 dworking ays after received the 30% deposit.
Welcome Contact Us For A Discount Now~
